OpenScape Desk Phone IP シリーズ

Unify IP-PBX OpenScapeシリーズで使用できる Desk Phone CPシリーズが追加されました。
シンプルさそして高品質のオーディオをお試しください。

製品ラインナップ

CP100 CP200
CP205
CP400 CP600 CP600E CP700
CP700X
OSDPCP100 OSDPCP200 OSDPCP400 OSDPCP600 OSDPCP600E OSDPCP700X

Detailed feature description

外観ディスプレイKeys/LEDインターフェースアプリケーションTechnical data
Feature OpenScape Desk Phone 100 OpenScape Desk Phone CP200/CP205 OpenScape Desk Phone CP400 OpenScape Desk Phone CP600/CP600E OpenScape Desk Phone CP700/CP700X
Body color
Black
CP700: Black
CP700X:Black/Silver
Standing Positions
two positions
Handset and Stand with Company logo
Yes
Feature OpenScape Desk Phone CP100 OpenScape Desk Phone CP200/CP205 OpenScape Desk Phone CP400 OpenScape Desk Phone CP600/CP600E OpenScape Desk Phone CP700/CP700X
Display Size
Graphical three line display, 162*48 Pixel
Graphical two line display, 192*48 Pixel
Graphical display, 3,7 inch, 240*120 Pixel
Graphical TFT display, 4.3”
(480*272 pixel)
Graphical TFT display, 5.0”
(800*480 pixel)
Display Color
Monochrome
CP600: Colored, 16 bit color depth
CP600E: 256 greyscales
Colored, 16 bit color depth
Backlight
No
Yes
Adjustable
No
Yes
Additional optical alert
Yes (red)
Yes (red/green/orange)
Feature OpenScape Desk Phone CP100 OpenScape Desk Phone CP200/CP205 OpenScape Desk Phone CP400 OpenScape Desk Phone CP600/CP600E OpenScape Desk Phone CP700/700X
Fixed function keys
2; Settings, Messages
5, thereof 3 with LED; Hold, Transfer, Conference, Settings, Messages
2; Menu, Out-of-Office
7; Menu/Presence/Voicemail/Hold/
Transfer/Conference and Redial
Free programmable keys
3 with status indication on the LCD display
4 with LED (red/green/orange)
16 with LED (red/green/orange)
None, Alternative: via Favourites menu
6 with LED (red/green/orange),
6 Favourites additionally
Pre-programmed keys
Call Log, Call forwarding, Redial
Call Log, Contacts, Call forwarding, Redial
None
Key labeling
Display
Paper
Paper
Display
Audio Keys
2; Mute, Loudspeaker and Volume +/-
3 with LED; Mute, Loudspeaker, Headset and Volume +/-
Navigation
3-Way Navigation-key and OK-Button
4-Way Navigation-key and OK-Button
Feature OpenScape Desk Phone CP100 OpenScape Desk Phone CP200/CP205 OpenScape Desk Phone CP400 OpenScape Desk Phone CP600/CP600E OpenScape Desk Phone CP700/CP700X
VoIP Protocol (or details check section Interoperability Matrix)
SIP (for OpenScape Voice and OpenScape 4000) & HFA (for OpenScape Business)
SIP (for OpenScape Voice and OpenScape 4000) & HFA (for OpenScape 4000 and OpenScape Business)
LAN Connectivity
10/100 MBit/s Ethernet autosensing
CP200: 10/100 MBit/s Ethernet autosensing
CP205: 10/100/1000 MBit/s Ethernet autosensing
10/100/1000 MBit/s Ethernet autosensing
Energy Efficient Ethernet (IEEE 802.3az)
No
CP200: No
CP205: Yes
Yes
Power over Ethernet (PoE, IEEE 802.af)
Yes
PoE Class
1
2
CP700:2
CP700X:3
Energy Saving Mode
No
Yes
Integrated Ethernet Switch for PC connection
Yes
LAN activity monitor for sending and receiving for both ports (part of menu)
Yes
Wi-Fi 5 (802.11ac)
No
CP700:No
CP700X:Yes
Headset jack for wired (121 TR9-5) and wireless Headsets (121 TR9-5*)
No
Yes

Bluetooth 2.1 BR/EDR:

  • HSP (Headset Profile)
  • HFP (Hands-free Profile)
  • OPP (Object Push Profile)
No
CP600: Yes
CP600E: No
Yes
Bluetooth Low Energy 4.1
No
CP600: Yes
CP600E: No
No
Bluetooth Low Energy 5.0
No
Yes
External conference unit
No
Yes, via cable
External conference unit connected via Bluetooth
No
CP600: Yes
CP600E: No
Yes

Passive RFID Tag with

  • Serial number = MAC Address
  • Part number
  • Manufacturing date and location
Yes

Passive NFC Tag with

  • Bluetooth MAC Address (Bluetooth simple paring)
  • LAN MAC Address (Mobility)
No
CP600: Yes
CP600E: No
Yes
SD Card
No
CP600: Yes
CP600E: No
No
Key Module Connector
No
Yes, up to 2 Key Modules KM400
Yes
CP600: Up to 4 Key Modules KM600
CP600E: Up to 2 Key Modules KM600
Yes, CP700: Up to 2 Key Modules KM600
CP700X: Up to 4 Key Modules KM600
Feature OpenScape Desk Phone CP100 OpenScape Desk Phone CP200/CP205 OpenScape Desk Phone CP400 OpenScape Desk Phone CP600/CP600E OpenScape Desk Phone CP700/700X
Telephony
Yes
Personal phone book/contacts
Yes, up to 100 locally for SIP only. For HFA this functionality is controlled / defined by the communication system
Yes, up to 1000 conversations with contact information
Local call log
Yes (configurable), 30 entries for each category (dialed, received, missed, forwarded calls) for SIP. For HFA there’s no local list and the functionality is controlled / defined by the communication system.
(dialed,received,missed,forwarded Calls)
3000 entries


Picture Clip
No
Yes
LDAP Client for corporate directory
Yes, for SIP only. For HFA there’s no local LDAP client. The functionality is controlled / defined by the communication system.
Yes
UC integration with OpenScape Business
No
Yes
Screen saver
No
Yes
Microsoft? Exchange connector
No
Yes
Operating system
Linux
User Interface Language

SIP: Basque, Brazil, Bulgarian, Catalan, Croatian, Czech, Danish, Dutch, English (USA), English (UK), Estonian, Finnish, French, German, Greek, Hungarian, Indonesian (with Latin characters), Italian, Latvian, Lithuanian, Macedonian, Malayan (with Latin characters), Norwegian, Polish, Portuguese, Romanian, Russian (in Cyrillic characters), Serbian (in Latin and Cyrillic characters), Slovak, Slovenian, Swedish, Spanish, Turkish and Welsh
HFA: All languages which can be configured in OpenScape Business as well as OpenScape 4000 are supported by the CP Phones.

Admin. Language (local admin. menu/web based management)
English
Feature OpenScape Desk Phone CP100 OpenScape Desk Phone CP200/CP205 OpenScape Desk Phone CP400 OpenScape Desk Phone CP600/CP600E OpenScape Desk Phone CP700/700X
Dimension

Angle x Height [mm] x Width [mm] x Depth [mm]

17° x 100 x 161 x 200
51° x 170 x 161 x 146
20° x 113 x 219 x 165
45° x 173 x 219 x 207
20° x 143 x 283 x 165
45° x 189 x 283 x 207
20° x 150 x 219 x 207
45° x 193 x 219 x 165
20° x 114 x 251 x 214
45° x 174 x 251x 167
Weight [kg]
1,0
1,0
1,2
1,0
1,4
Wall mountable
Yes, Wall mount unit in the stand
Yes
No
Yes (not with Key Modul KM600)
Europe

USA/Canada

CE
NRTL
Safety standards
IEC 60950-1
IEC 62368-1
EN 62368-1
UL 62368-1
CAN/CSA 22.2 No. 62368-1
IEC 60950-1
IEC 62368-1
EN 62368-1
UL 62368-1
CAN/CSA 22.2 No. 62368-1
IEC 60950-1
IEC 62368-1
EN 62368-1
UL 62368-1
CAN/CSA 22.2 No. 62368-1
Hearing Aid compatibility
FCC Part 68 (CFR 47) / CS-03 Part V
Storage conditions
-40°C to +70°C
Operational conditions
+5°C to +70°C
Power supply

Remark: The same PSUs as already been used for OpenStage and Desk Phone IP Phones.

Yes, optional
Yes, optional; from 2nd Key Modul KM600 mandatory
CP700: Yes, optional; from 2nd Key Modul KM600 mandatory
CP700X: Yes, optional; for all four KM600 not mandatory
